Without Connector

A1S-XVBA12

PLEASE SELECT PRODUCT ITEM NO.

Add to Inquiry

CAD data (Download)

Specification	Data
Specifications
Product Name	12P 訊號中繼模組
No. of Poles	12P (poles)
Correspondence with PLC/CNC Brands	通用款
Polarity (PLC Output)
Subtable Purpose	適用於中大型 PLC 輸出模組外接訊號轉板、控制設備輸出
LED Indicator	無
Dimensions	L77.0 X W86.0 X H42.4 mm
Brands of Terminal Block	WAGO
Types of Terminal Block	5.0mm 直插彈片式端子台
Types of Connector	無
Contact Protection	N
Types of Bottom Shield	鎖鋁軌
Specifications
Performance
Rated Voltage	AC - 125V ~ DC - 30V
Rated Current (mA)	8A
Withstand Voltage	AC - 500V 1分鐘
Insulation Resistance (Ω)	100 MΩ
Applicable Wire Diameter	12~28 AWG
Material Information
Materials of Module	塑膠本體、 PCB板 (FR-4 玻璃纖維)
Weight (g)	約 62.5g
Commerical Data
H.S. Code	8517.62.00.00-5
Place of Origin	Taiwan (R.O.C)
Installation
Modules	DIN-35mm 標準導軌式安裝
Certifications
International Certification	CE、FCC、RoHS
